LES SL

A Race Bike Bullet Train

On the right course, nothing is faster than a hardtail, and nothing delivers the stiffness to weight ratio and raw speed as a Pivot LES SL. The LES SL is engineered to the Nth degree to deliver the kind of handling, extreme power transfer and weight that transforms every last watt of output into a race-winning performance.

Hardtail

Rear Travel

29"

Wheel Size

Carbon

Material

DOMINANT SPEED

Rip through the field with dominance usually reserved for fighter jets and bullet trains. The LES SL’s modern, progressive geometry and innovative carbon science provides the ideal vertical compliance and liveliness to launch you at the starting line and propel you late in the race.

LES IS MORE

The LES is more of everything you want and need in an ultra-lightweight hardtail: performance, compliance and speed. Designed to achieve one of the lightest production hardtail frames in the world at just over 800 grams for a medium; the LES SL’s featherlight status is the result of years of research. In that regard, the LES is also less: less weight, less resistance, fewer unnecessary grams.

Build Your LES SL

We strive to build the best-performing cycling products in the world.

LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ
LES SL - Pivot Cycles NZ

LES SL

$9,995.00 NZD

*PRO XT WITH CARBON WHEELS - MEDIUM BLUE RIBBON AVAILALBE | WHILE STOCKS LAST
*TEAM XTR WITH CARBON WHEELS - LARGE BLUE RIBBON AVAILABLE | WHILE STOCKS LAST

BUILD SPECS

Table header 0PRO XT/XTRTEAM XTR
RRP$9995 NZD (Was $11,995)$11,995 NZD (Was $13,995)
BRAKES Shimano XT M8100 2-Piston Shimano XTR M-9100
CASSETTE Shimano XT M8100 10-51t Shimano XTR M9100 10-51t
CHAIN Shimano CN-M8100 12-Speed Shimano CN-M9100 12-Speed
CRANKSET Race Face Aeffect R 34t - 175mm Race Face Next SL 34T - 175mm
DERAILLEUR Shimano XTR SGS 12-Speed Shimano XTR SGS 12-Speed
FORK Fox Factory Stepcast 32 29" w/ Remote, 44mm offset - 100mm Fox Factory Stepcast 32 29" w/ Remote, 44mm offset - 100mm
GRIPS Phoenix Factory Lock-On Phoenix Factory Lock-On
HANDLEBAR Phoenix Team Flat Carbon - 760mm Phoenix Team Flat Carbon - 760mm
HEADSET Pivot Precision Sealed Integrated Cartridge Pivot Precision Sealed Integrated Cartridge
REAR SHOCK N/A N/A
ROTOR Shimano XT RT81 CenterLock - 160mm Shimano XTR RT-MT900 CenterLock - 160mm
SADDLE Phoenix WTB Race Volt Phoenix WTB Pro Volt
SEATPOST Phoenix Pro Carbon Phoenix Team Carbon
SHIFTER Shimano XT M8100 12-Speed Shimano XTR M9100 ISPEC 12-Speed
STEM Phoenix Team XC/Trail - 90mm Phoenix Team XC/Trail - 90mm
TIRE FR Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI
TIRE RR Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI
WHEELS DT Swiss M1700 w/ DT Swiss 350 hub & 36T Star Ratchet 25mm - 29" Reynolds Blacklabel 309/289 XC w/ Industry Nine Hydra hub 30mm F 28mm R - 29"
Table header 0PRO XT/XTRRRP
WHEEL UPGRADE OPTION Reynolds Blacklabel 309/289 XC w/ Industry Nine Hydra hub 30mm F 28mm R - 29" + $2000 NZD
Table header 0PRO X01TEAM XX1 AXS
RRP$11,995 NZD$15,995 NZD
BRAKES Sram Level TLM SRAM LEVEL Ultimate
CASSETTE Sram XO1 XG-1295 10-50t Sram XX1 XG-1299 10-50t
CHAIN Sram XO1 12-SpeedSram XX1 AXS 12-Speed
CRANKSET Sram XO1 Eagle DUB 32t - 175mmSram XX1 Eagle DUB SL 32t - 175mm
DERAILLEUR Sram XO1 12-SpeedSram XX1 12-Speed
FORK Fox Factory Stepcast 32 29" w/ Remote, 44mm offset - 100mmFox Factory Stepcast 32 29" w/ Remote, 44mm offset - 100mm
GRIPS Phoenix Factory Lock-On Phoenix Factory Lock-On
HANDLEBAR Phoenix Team Flat Carbon - 760mmPhoenix Team Flat Carbon - 760mm
HEADSET Pivot Precision Sealed Integrated Cartridge Pivot Precision Sealed Integrated Cartridge
REAR SHOCK N/A N/A
ROTOR Sram Centerline Centerlock - 160mm Sram Centerline Centerlock - 160mm
SADDLE Phoenix WTB Pro Volt Phoenix WTB Team Volt
SEATPOST Phoenix Pro Carbon Phoenix Team Carbon
SHIFTER Sram XO1 12-Speed Sram XX1 AXS 12-Speed
STEM Phoenix Team XC/Trail - 90mm Phoenix Team XC/Trail - 90mm
TIRE FR Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPIMaxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI
TIRE RR Maxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPIMaxxis Ikon 29" x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI
WHEELS DT Swiss M1700 w/ DT Swiss 350 hub & 36T Star Ratchet 25mm - 29"Reynolds Blacklabel 309/289 XC w/ Industry Nine Hydra hub 30mm F 28mm R - 29"
Table header 0PRO x01RRP
WHEEL UPGRADE OPTION Reynolds Blacklabel 309/289 XC w/ Industry Nine Hydra hub 30mm F 28mm R - 29" + $2000 NZD

Graphics, colors, and specifications are subject to change without prior notification.

QUALITY CRAFTSMANSHIP

GEOMETRY AND SIZING

We strive to build the best-performing cycling products in the world.

Table header 0XSSMMDLGXL
A: Seat Tube Length (C-T)35.5 cm 39.5 cm 42.0 cm 47.0 cm 51.0 cm
B: Top Tube Length56.5 cm 59.2 cm 62.0 cm 63.8 cm 66.8 cm
C: Head Tube Length 8.5 cm 9.0 cm 10.0 cm 11.0 cm 13.0 cm
D: Head Tube Angle 68° 68.5° 68.5° 68.5° 68.5°
E: Seat Tube Angle75° 74.5° 74.5° 74.5° 74.5°
F: Chain Stay Length 42.9 cm 42.9 cm 42.9 cm 42.9 cm 42.9 cm
G: Bottom Bracket Height 31.0 cm 31.0 cm 31.0 cm 31.0 cm 31.0 cm
H: Bottom Bracket Drop6.4 cm 6.4 cm 6.4 cm 6.4 cm 6.4 cm
I: Standover Height6.2 cm 6.4 cm 6.6 cm 6.7 cm 6.7 cm
J: Wheelbase108.6 cm 110.3 cm 113.2 cm 115.0 cm 118.3 cm
STACK59.4 cm 60.1 cm 60.1 cm 62.0 cm 63.8 cm
REACH40.0 cm 42.0 cm 44.5 cm 46.0 cm 48.5 cm

Engineer's Corner

Get everything you need to know about the LES SL.

  • Ultra-Featherlight Hollow Core Carbon Frame (800g)
  • Best-in-Class Stiffness to Weight Ratios
  • Lightweight Integrated Headset
  • New-school hardtail racing geometry
  • Low Standover Fits Riders 4’10” to 6’ 7”
  • Internal Routing with Pivot Cable Port System
  • Pivot Dock Tool System Compatible, Under the Top Tube and Bottom Bracket
  • Featuring the easy to find UDH rear derailleur hanger for peace of mind when traveling

To ensure the best sizing, we recommend that you visit your local Pivot dealer to get a professional fit and refer to our geometry chart to check your measurements. However, we can provide a rough guideline:

 XS: 4'10" – 5’5” (147cm - 165cm)

Small: 5'3" – 5’8” (160cm - 172cm)

Medium: 5'5” – 5’11” (165cm - 180cm)

Large: 5’10”– 6’1” (178cm - 185cm)

X-Large: 6'1" + (185cm +)

Yes, internally routed dropper posts are compatible with the LES SL.

There are limitations that each dropper post has for each frame size based on the rider’s saddle height, so it is important to check the fit before choosing the travel and model of dropper post for your LES SL. Use the Dropper Fit Guide under the Tech Specs section to help identify the right post length. 27.2mm

28.6mm

XS- 230mm
S - 240mm
M - 260mm
L - 300mm
XL - 390mm

*Please check seat post measurements carefully before installing the post.

The LES SL uses Boost 148mm x 12mm hub/wheel spacing. This hub design has wider flanges, so you cannot change the end caps to convert an existing 135mm, 142mm, 150mm, or 157mm hub.

The new LES SL does not use our Swinger adjustable dropouts so there is no adjustment built into the frames for easy chain tensioning. That said, If you want to set up the LES SL as a single speed, you will need an independent chain tensioner that attaches to the derailleur hanger in place of the derailleur.

29” x 2.4 WT XC Specific tires is the widest on a 28-30mm rim.

The LES SL is only compatible with 29” wheels

The Les SL uses the new Universal Derailleur Hanger (UDH) standard developed by SRAM. This derailleur hanger is compatible with all derailleurs on the market – not just SRAM. We spec this hanger because it has some clever derailleur saving features and is more likely to be found at any shop and are also available in our webstore.

The Les SL uses an axle for 148mm rear spacing designed for the new Universal Derailleur Hanger (UDH) standard. The rear axle supplied with the frame is a Pivot specific design using a 12mm X 1.0mm thread pitch. SRAM also makes compatible 148mm UDH axles.

The LES SL will accept all cranks designed for the BOOST system and compatible with a Press Fit 92mm bottom bracket. BOOST system means that the rear hub spacing is 148mm and the chain-rings have (approximately) a 52mm chainline.

The LES SL uses a Pressfit BB92 (PF92) bottom bracket. All major crank manufacturers and many aftermarket companies make PF92 bottom brackets. However, if you are running a crank with a 30mm diameter spindle (like Race face) we highly recommend using a bottom bracket with a double row bearing design such as our Pivot Enduro BB.

163mm

38t

No, the LES SL is designed to be 1x only.

The LES SL was designed for 100mm to 120mm fork travel. 120mm is the maximum travel length to be used on the LES SL. We use the FOX 32 Step Cast 100mm fork in all our complete bike builds. This fork is a 29” race-specific fork designed for 29” wheels with up to 2.3” tires and is NOT compatible with 27.5+ tires.

An e-type side-swing style front derailleur - Shimano produces the e-type side-swing front derailleur in:

- Deore & SLX for 10-speed drivetrains

- XT & XTR for 11-speed drivetrains

- SLX, XT & XTR for 12-speed drivetrains

44mm

For the LES SL, we use an integrated style headset. The upper bearing measures 1-1/8" with 45°/45° ACB & has an OD of 41.8mm. The lower bearing measures 1-1/2" with 45°/45° ACB & has an OD of 51.9mm.

180mm

No rear brake adapter is needed for a 160mm rotor. If you would like to put a 180mm rotor on, you will need a direct mount post-to-post adapter.

A detailed PDF of the torque specs can be found in the Tech Specs section.

A size medium LES SL frame weighs just 1.7 lbs (800 grams). The complete Team XTR build weighs 19.8 lbs (9 kg.) Pivot bicycles are among the lightest available, but the weight is only one of many factors that make a great bicycle. Other aspects such as frame stiffness, strength, durability, and ride quality are just as important as weight to our engineers when designing our Hollow Core Carbon frames. Instead of comparing grams online, we suggest you visit your local Pivot dealer and see our attention to detail, smart, high-value spec, and class-leading features. Bring a scale if you’d like but take just one demo ride and you’ll feel why Pivot Cycles are the most well-rounded, highest performing bicycles on the market and in many cases, yes, it’s the lightest as well.
